Freightliner Lower Coolant Tube OEM: A05-15637-000

Description

This is an identical replacement part for factory coolant tubes (OEM: A05-15637-000).

Manufactured in AMERICA from 304 stainless steel, hand tig welded with mandrel bends and machined fittings.  No miter cut bends, cast fittings, or wire welding.

• Tube inlet size: 2-1/2″ Beaded
• Tube outlet size: 3″ Beaded
• Hose beaded: Yes
• Fitting sizes: (3) 1/2″ NPT & (1) 3/4″ NPT
• Base tube dia. 2-1/2″
• Material: 304 stainless steel

Drawing
